Introduction:
Fix the external support foot of the motor side of the lifting accessories coupling, and move the inner support foot until the eccentric line of the motor and the pump center is zero.
How to align the coupling:
(1) Fixed lifting accessories coupling motor side of the external support foot, move the inner support foot, until the motor and pump center eccentricity line is zero. In order to ensure that the motor does not move arbitrarily, after fixing the foot of one side of the motor, the other side should be supported by the top wire.
(2) Fix the inner support foot of the coupling and move the outer support foot so that the eccentricity of the two center lines is zero.
(3) After repeating the above two methods for several times, the coupling can be in a good alignment state.
To sum up:
Finding coupling of lifting accessories is an important work in the process of equipment maintenance. The principle of finding the right is simple, but practical. In the small machine pump often used to find the method of single table method, double table method and three table method and so on. Either way, there is a common feature; The alignment in horizontal plane is more prone to error than that in vertical plane. It has strong repeatability, time-consuming and complicated calculation.
